Gold Bonding Wire
Features
If you currently use bonding wires from other renowned brands, rest assured that switching to our products will not require any process changes. We are highly confident in the quality of our bonding wires. Please don’t hesitate to reach out to us for further information.
Mechanical Properties
Diameter |
B/L(gf) |
E/L(%) |
|||
μm |
mil |
YG1 |
YG5 |
YG9/YG10 |
YG |
16±1 |
0.65 |
＞2.0 |
＞3.0 |
＞4.0 |
2.0-5.0 |
18±1 |
0.7 |
＞2.5 |
＞4.0 |
＞5.0 |
2.0-5.0 |
19±1 |
0.75 |
＞3.0 |
＞4.5 |
＞5.5 |
2.0-6.0 |
20±1 |
0.8 |
＞3.0 |
＞5.0 |
＞6.0 |
2.0-6.0 |
23±1 |
0.9 |
＞5.0 |
＞7.0 |
＞8.0 |
2.0-7.0 |
25±1 |
1.0 |
＞7.0 |
＞9.0 |
＞10.0 |
2.0-8.0 |
30±1 |
1.2 |
＞10.0 |
＞13.0 |
＞15.0 |
3.0-8.0 |
33±1 |
1.3 |
＞13.0 |
＞16.0 |
＞18.0 |
3.0-8.0 |
38±1 |
1.5 |
＞17.0 |
＞21.0 |
＞26.0 |
3.0-10.0 |
50±2 |
2.0 |
＞30.0 |
＞35.0 |
＞37.0 |
3.0-12.0 |
Fusing Current&Hardness
Type |
YG1 |
YG5 |
YG9 |
YG10 |
||
|
μm |
mil |
||||
|
Fusing current (A,10mm) |
16 |
0.65 |
0.34 |
0.31 |
0.22 |
0.20 |
18 |
0.70 |
0.38 |
0.35 |
0.26 |
0.25 |
|
20 |
0.80 |
0.42 |
0.39 |
0.28 |
0.28 |
|
23 |
0.90 |
0.49 |
0.46 |
0.32 |
0.31 |
|
25 |
1.00 |
0.53 |
0.50 |
0.35 |
0.35 |
|
30 |
1.20 |
0.63 |
0.60 |
0.42 |
0.41 |
|
33 |
1.30 |
0.70 |
0.67 |
0.46 |
0.44 |
|
38 |
1.50 |
0.80 |
0.77 |
0.53 |
0.51 |
|
50 |
2.00 |
1.06 |
1.04 |
0.70 |
0.68 |
|
|
Hardness (Hv) |
Wire |
54-58 |
58-62 |
67-71 |
70-74 |
|
FAB |
44-48 |
48-52 |
57-61 |
60-64 |
||
